Parent Layer: [+] Structure

Name: MNSM Faults; MRCI (2021kygs)

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="margin:0 0 11 0;"><SPAN>This is a compilation dataset showing the location of faults and other structures that penetrate and affect the Mount Simon-Lamotte Sandstone in the MRCI region.</SPAN></P><P STYLE="margin:0 0 11 0;"><SPAN>Compilation data files are from Trenton-Black River Appalachian Basin Exploration, 2006; Illinois Bedrock Faults 500K, 2005; J.B. Hickman , Univ. Kentucky PhD dissertation, 2011; State Geologic Map Compilation (SGMC) geodatabase, 2017; Missouri Geological Survey, 2018; Missouri Tectonic Fault Structures 2010; Michigan Geological Repository for Research and Education, 2021; Iowa Geological Survey, 2021; and Marshak, et al, 2017.</SPAN></P><P><SPAN>Author/Originator: Tom Sparks, Kentucky Geological Survey</SPAN></P><P><SPAN>Date Created: 2021</SPAN></P></DIV></DIV></DIV>

Service Item Id: 79390002021d498e9df688461b356154

Copyright Text: Midwest Regional Carbon Initiative (MRCI)

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: false

Supports Statistics: false

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -4125934.0972124115
YMin: -2416262.4848716967
XMax: -125709.58786718428
YMax: 1854208.1764215985
Spatial Reference: 0  (0)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [230, 0, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 35
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: false
Supports OrderBy: false
Supports Distinct: false
Supports Pagination: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: false
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: false
Supports Having Clause: false
Supports Count Distinct: false
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• FID ( type: esriFieldTypeOID, alias: FID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• OBJECTID ( type: esriFieldTypeInteger, alias: OBJECTID )
• FLT_SYSTEM ( type: esriFieldTypeString, alias: FLT_SYSTEM, length: 40 )
• DOWNTO ( type: esriFieldTypeString, alias: DOWNTO, length: 6 )
• PCOFFSET ( type: esriFieldTypeString, alias: PCOFFSET, length: 6 )
• YOUNGEST_O ( type: esriFieldTypeString, alias: YOUNGEST_O, length: 40 )
• CONFIDENCE ( type: esriFieldTypeInteger, alias: CONFIDENCE )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, length: 40 )
• NAME ( type: esriFieldTypeString, alias: NAME, length: 20 )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 8 )
• Shape_Leng ( type: esriFieldTypeDouble, alias: Shape_Leng )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
