Parent Layer: [+] CO2

Name: RSRN CO2 (kt CO2/km2); OH(AB) (2021ocdo-g)

Display Field:

Type: Raster Layer

Geometry Type: null

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>As part of a study, "CO2 Storage Resources and Containment Assessment in the Cambrian and Ordovician Formations of Eastern Ohio," the volumetric method as put forth by the U.S. Department of Energy (DOE) National Energy Technology Laboratory (DOE-NETL, 2008; 2010; Goodman et al., 2011) was used to quantify and map the prospective CO2 storage resources of nine saline formations--the Rose Run being one of the nine.</SPAN></P><P><SPAN>Using a dataset consisting of well logs from a total of 413 wells in the study region, with ~40 to 200 control points per unit, petrophysical properties were calculated and mapped. Core porosity and permeability data for ~15 wells were used to perform quality checks of the log data and interpolated maps trends. The well data and petrophysical properties were imported into Petrel and used to build a regional Static Earth Model (SEM). A heterogeneous (300 grid cell) calculation was carried out to estimate the CO2 storage resource for each unit using the SEM. To correct for pore volumes lost around the perimeter of the grid, the pore volume of each grid cell was summed and the resulting volume was scaled up to total formation area to determine the total pore volume.</SPAN></P><P STYLE="margin:0 0 11 0;"><SPAN>Author/Originator: Battelle</SPAN></P><P STYLE="margin:0 0 11 0;"><SPAN>Date Created: 2017 / 2021</SPAN></P></DIV></DIV></DIV>

Service Item Id: 4298427439e14b5792e442b7b5b07939

Copyright Text: Ohio Coal Development Office (OCDO)

Default Visibility: false

MaxRecordCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: false

Supports Statistics: false

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -397999.49625009636
YMin: -1539443.7271161857
XMax: 415648.8237499036
YMax: -184456.80711618564
Spatial Reference: 0  (0)  LatestVCSWkid(0)

Drawing Info:

N/A

Advanced Query Capabilities:

Supports Statistics: false
Supports OrderBy: false
Supports Distinct: false
Supports Pagination: false
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: false
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: false
Supports Having Clause: false
Supports Count Distinct: false
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields: None


Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
