Layer: NDMR Structure Top (Ft); PA/MD/WV (2005mrcsp1) (ID: 323)

Parent Layer: [+] Structure

Name: NDMR Structure Top (Ft); PA/MD/WV (2005mrcsp1)

Display Field:

Type: Raster Layer

Geometry Type: null

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This file is a component of the digital structure contour map of the top of the Needmore Formation in Maryland, West Virginia and Pennsylvania (1:500,000 scale). The contour map is based on available borehole data for the Needmore Formation provided by West Virginia, Pennsylvania and Maryland and compiled by the Maryland Geological Survey. The contour map includes the elevation data points (relative to mean sea level) and the lines contouring the estimated top of formation at a 500-foot contour interval. Location coordinates for the data points are from published and previously unpublished records. This file includes only the structure lines developed as digital line (arc) features in ESRI ArcGIS shapefile format. Structure contours (500-foot contour interval) were constructed by interpolation using Ordinary Kriging and subsequent minor manual methods applied to a selected dataset of available elevations of the top of formation from the compiled borehole information. The Ordinary Kriging was completed using the Geostatistical Analyst extension in ESRI's ArcGIS software. The feature attribute table, which is part of this file, includes the elevation represented by each contour line. The selected elevation data points used to develop the contour lines are provided in the associated point shapefile, NEED_TOP_PTS_MRCSP (see metadata associated with that file for details). This file and the related Needmore Formation Structure Contour Map, showing the elevation of the top of the unit, are provided in a projection specifically developed for this project, referred to as MRCSP_North_America_Albers_Equal_Area_Conic. This projection is an Albers Equal Area Conic NAD83 projection (in survey feet) that was adjusted by the MRCSP as follows: the central meridian to -82.0 degrees, and the standard parallels to 38.5 and 43 degrees (to better bracket the project's specific area of use).</SPAN></P><P><SPAN>Production of the digital geospatial data set was funded, in part, by the United States Department of Energy's National Energy Technology Laboratory (DOE/NETL) via the Midwest Carbon Sequestration Partnership (MRCSP), which is led by Battelle. The MRCSP--of which the MGS is a partner--is one of seven regional partnerships established by the U.S. DOE/NETL. The views and the opinions of authors expressed herein do not necessarily state or reflect those of the members of the MRCSP, the United States Government or any agency thereof.</SPAN></P><P><SPAN>The Maryland Geological Survey received support in the development and production of the digital geospatial data set in ArcGIS format from Towson University, Center for Geographic Information Sciences.</SPAN></P><P><SPAN>Author/Originator: Maryland Geological Survey</SPAN></P><P><SPAN>Date Created: 2005</SPAN></P></DIV></DIV></DIV>

Service Item Id: 3a55f6b38a874c069a1522edfe711a0d

Copyright Text: Midwest Regional Carbon Sequestration Partnership (MRCSP) and the Midwest Regional Carbon Initiative (MRCI)

Default Visibility: false

MaxRecordCount: 0

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: false

Supports Statistics: false

Has Labels: false

Can Modify Layer: false

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

Drawing Info:

N/A Advanced Query Capabilities:

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields: None

Supported Operations: Query Query Attachments Query Analytic Generate Renderer Return Updates

Iteminfo Thumbnail Metadata
