Name: Regional Geologic Cross Sections; MRCI (2024kygs) [P,L]

Display Field: XSec_Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This is a dataset showing the profiles of cross sections that illustrate the nature of the stratigraphy, structure, and wells from the surface to Precambrian basement. These cross sections were constructed to help industry, policy makers, and the general public visualize the geology of rock units relative to geologic carbon storage as part of the Midwest Regional Carbon Initiative and Midwest Regional Carbon Sequestration Partnership research.</SPAN></P></DIV></DIV></DIV>

Service Item Id: 1388757329c445baa52efeae0d23caef

Copyright Text: -Midwest Regional Carbon Initiative (MRCI) -Midwest Regional Carbon Sequestration Partnership (MRCSP) Dinterman, P., Greb, S.F., Lewis, J.E., Schmelz, W.J., Sparks, T.N., Solis, M.P., Medina, C., Carter, K.M., Barnes, D.A., Harper, J.A., Harrison, W.B., Moore, J.P., Miller, K.G., Hickman, J., Riley, R.A., McDowell, R., Rupp, J., Browning, J.V., and Gupta, N., 2020, Regional cross sections for potential storage and containment zones in the MRCSP region: U.S. Department of Energy, DOE MRCSP Project #DE-FC26-05NT42589, 19 p., 2 appendices, 6 plates, https://doi.org/10.2172/1755650

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF
